Raw Materials
The cab, body, boom and frame of a telescoping boom rough terrain forklift are normally manufactured by a forklift manufacturer. The most popular material used for these subassemblies is steel, because of its amazing strength. At times steel forgings or aluminum are used too. It is common for non-metallic materials like nylon plastic blocks to be used as guides within the boom assembly. The other components are typically bought as finished products and the forklift manufacturer installs them.
Several of the pre-assembled bought products consist of the transmission, seat, engine, axles, wheels, hoses and tires, lights, back-up alarms, hydraulic cylinders and gauges. Usually, some materials like for instance the lubricants and hydraulic fluid and fuel are purchased in bulk. These liquids are added as needed once the machinery is assembled and has passed the rigorous testing sessions.
Design
The common design that is most typical of telescoping boom rough terrain forklifts is a long and narrow design that has a set of wheels at the front of the model and another set located towards the rear of the equipment. The unit's boom is mounted at the back of the forklift off of a pivot feature which is elevated a few feet above the level of the frame. Normally, the cab is mounted on the left-hand side of the frame structure. Typically, the bottom half of the cab is low and located between the tires. The fuel tank and the hydraulic fuel tank are mounted opposite the cab on the right-hand side. Along the vehicle's center-line, the transmission and the engine are mounted inside the frame.
Various manufacturers have contributed their own unique designs beyond this basic configuration. These days, there are numerous options available on the market. Some models of forklifts use a single hydraulic cylinder to be able to raise the boom, and other models utilize 2 cylinders. Several models utilize a side-to-side hydraulic frame leveling capability. This particular feature enables the frame to tilt up to 10 degrees relative to the axles so as to allow the machinery to compensate for extreme axle articulation. This is used for example, when the tires on one side of the forklift are situated down in a rut and the tires on the other side of the machine are up, situated on a mound of dirt.
One more common design feature comprises fork attachments that are capable of swinging up to 45 degrees both left and right, in order to allow precise load positioning.
